Delivery of a compliant and technically coordinated curtain walling, louvre, and automated entrance package for Winslow Station, meeting Network Rail standards within a complex infrastructure environment.
Project Details
TL;DR:
Advanced Glass delivered a comprehensive façade package for Ilford Train Station in London, working for VolkerFitzpatrick over a six-month programme. The live rail environment required strict adherence to National Rail design standards, phased deliveries during off-peak hours and fully PTS-qualified operatives.
The package included Technal curtain walling, ST2 doors, automatic bi-parting sliding doors, Litho Décor glass rainscreen cladding, bespoke pressed metal cladding solutions and RC3-rated steel security doors.
A key challenge involved coordinating multiple penetrations and interfaces through the cladding system, requiring bespoke detailing to maintain performance and buildability. Despite working within a live station environment and complex façade interfaces, the project was delivered on budget and met all design and security requirements.
The scheme demonstrates Advanced Glass’ capability in delivering compliant façade systems within high-security and operational infrastructure environments.
Ilford Train Station is a live rail infrastructure project delivered in London for VolkerFitzpatrick over a six-month programme. Operating within an active public transport environment required careful sequencing, strict safety controls and adherence to National Rail design requirements.
The project demanded robust façade systems capable of integrating security, weather performance and durability within a highly operational setting.
Scope of Works
Advanced Glass was appointed to supply and install Technal curtain walling and ST2 doors, alongside automatic bi-parting sliding doors serving public entrance areas. The façade also incorporated Litho Décor glass rainscreen cladding and bespoke pressed metal cladding elements, developed to accommodate complex architectural and service requirements.
Steel security doors rated to RC3 classification were integrated within the envelope to meet project security specifications. No off-site fabrication was utilised, with all elements installed within the live site constraints.
Design and Technical Challenges
The primary technical challenge on this project involved coordinating numerous penetrations and service interfaces through the cladding system. These penetrations required bespoke detailing to ensure structural integrity, weather performance and long-term durability were maintained.
The bespoke pressed metal cladding solution was developed specifically to overcome these interface constraints while maintaining design intent and compliance with National Rail standards.
Working within a live rail environment also introduced additional complexity, requiring detailed planning and coordination throughout the design and delivery stages.
Installation and Programme
As a live train station, site access and logistics required careful control. Deliveries were scheduled during off-peak hours to minimise disruption to passengers and rail operations. All operatives were PTS trained and fully briefed on working adjacent to live rail lines.
Approximately nine Advanced Glass operatives were deployed on site at peak installation periods. Close coordination meetings ensured alignment with other trades and infrastructure teams.
Although the programme experienced minor delays, the façade package was delivered on budget and met all design requirements.
Security and Performance
Security was a key requirement, with RC3-rated steel doors integrated into the station envelope. All installed systems complied with National Rail design expectations and project-specific performance standards.
Outcome and Lessons Learned
The project was successfully delivered within a highly constrained and safety-critical environment. The façade met all specified design and security requirements and performed as intended.
The scheme reinforced the importance of upfront coordination and detailed interface planning when working on infrastructure projects with complex penetrations and live operational constraints.
Ilford Train Station demonstrates Advanced Glass’ capability in delivering technically robust façade solutions within live transport environments where safety, compliance and coordination are paramount.
